Texas Instruments TMP102 Digital Temperature Sensor

Texas Instruments TMP102 Low-power, two-wire, serial output temperature sensor with an I²C/SMBus digital interface is ideal for NTC/PTC thermistor replacement where high accuracy is required. The sensor is highly linear and does not require complex calculations or lookup tables to derive the temperature. The Texas Instruments TMP102 is ideal for extended temperature measurement in a variety of communication, computer, consumer, environmental, industrial, and instrumentation applications.

Features

SOT-563 package (1.6mm × 1.6mm) is 68% smaller footprint than SOT-23
Accuracy without calibration
- 2.0°C (max) from –25°C to 85°C
- 3.0°C (max) from –40°C to 125°C
1.4 to 3.6V supply range
12 bits resolution

Low quiescent current
- 10µA active (max)
- 1µA shutdown (max)
SMBus™, two-wire, and I²C digital output
Interface compatibility
NIST traceable

Applications

Portable and battery-powered applications
Power-supply temperature monitoring
Computer peripheral thermal protection
Notebook computers
Battery management
Office machines

Thermostat controls
Electromechanical device temperatures
General temperature measurements
- Industrial controls
- Test equipment
- Medical instrumentations
