STMicroelectronics STM32MP1微處理器系列

STMicroelectronics STM32MP1微處理器系列是能夠為廣泛的應用程式輕鬆部署的設備組合。STM32MP1系列基於各種各樣的單或雙Arm Cortex-A7及Cortex-M4內核架構。該系列支持多個和靈活的應用。Cortex-A7內核系統開源作業系統(Linux/Android)存取通道。Cortex-M4內核綜合利用STM32 MCU生態系統。

STM32MP13x is an STM32 Arm Cortex-A class microprocessor running at 650MHz and up to 1GHz. The STM32MP13x has additional features versus the STM32MP15x, including enhanced security capabilities and dual Ethernet.

The STM32MP13x MPUs offer an easier experience, reducing the time and cost of development thanks to a strong ecosystem for more security and longer battery life. The security level on the STM32MP13x has been significantly enhanced to protect data in any application, especially with connected devices to the cloud.

STM32MP13 comes in 3 different product lines
• STM32MP131 line
• STM32MP133 line with dual Ethernet and CAN FD
• STM32MP135 line with dual Ethernet, CAN FD, display, and camera.
All three lines have optional security features and enhanced CPU frequencies (i.e., up to 1GHz).

The STM32MP135 and the existing STM32MP1 Series can be combined with a dedicated Power Management IC (PMIC) designed by GPA ST's division. As an MPU, ST has an important ecosystem with software tools, hardware tools, strong partners, and a full, mainlined open-source Linux solution.

特點

核心
- 650MHz Arm Cortex-A7雙核
- 32kB+32kB I/D L1快取
- 256kB L2快取
- 209MHz Arm Cortex-M4核心
外部存儲器支援
- DDR3, DDR3L, LPDDR2, LPDDR3
- SLC NAND、SPI NAND
- eMMC、SD卡、Quad-SPI NOR
內部存儲器
- 256kB系統RAM
- 384kB MCU系統RAM
- 64kB MCU保留RAM
模擬
- 2x 16位ADC
- 2x 12位DAC
