Cole Hersee TR Dual-Pole Master Disconnect Switches

Cole Hersee TR Dual-Pole Master Disconnect Switches cut all battery power from vehicle electrical systems in applications needing switching of two circuits or both positive and negative. These switches feature a 500A continuous current rating for each of the two circuits (using 2x 4/0 input and 2x 4/0 output cables). The TR series can be used to switch two-vehicle voltage circuits simultaneously (24V and 12V). Cole Hersee TR Dual-Pole Master Disconnect Switches offer a maximum voltage rating of 32VDC. Ingress protection to IP67 and IP69K means that the switch can be mounted in exposed locations on vehicles.

Features

  • Can be mounted in exposed locations on vehicles
  • Drop-in replacement for competitive master disconnect switches
  • Higher vibration and shock capabilities
  • Direct lockout/tagout capability in on or off position, with padlock or hasp

Specifications

  • 32VDC maximum operating voltage
  • -50°C to +85°C operating temperature range, DC-rated to +105°C
  • IP67/IP69K ingress rating
  • Maximum continuous current per circuit
    • 500A with 2x 4/0 input and 2x 4/0 output cables
    • 350A with 1x 4/0 input and 1x 4/0 output cables

Configurations

Application Circuit Diagram - Cole Hersee TR Dual-Pole Master Disconnect Switches
