Bosch BMI330 Extended Temperature IMU
Bosch BMI330 Extended Temperature Inertial Measurement Unit (IMU) is a high-performance 6-axis sensor designed for demanding industrial and harsh-environment applications. The Bosch BMI330 IMU integrates a 3-axis gyroscope and a 3-axis accelerometer, delivering precise motion sensing with low noise and high stability across an extended -40°C to +105°C temperature range. Engineered for robustness, the BMI330 features advanced built-in self-test capabilities, vibration robustness, and a low total cost of ownership (TCO) due to long-term stability and reliability. The IMU supports multiple digital interfaces (I3C, I2C, and SPI) and is optimized for applications such as robotics, industrial/agricultural, and navigation systems. The compact LGA package and Bosch’s proprietary Force-Operating Compensation (FOC) technology ensure consistent performance even under mechanical stress and temperature fluctuations. With a combination of precision, durability, and flexibility, the BMI330 is ideal for mission-critical motion sensing in challenging environments.
Features
- Integrated components
- 16-bit digital, triaxial accelerometer with a range configurable to ±2g, ±4g, ±8g, and ±16g
- 16-bit digital, triaxial gyroscope with a range configurable to ±125°/s, ±250°/s, ±500°/s, ±1000°/s, and ±2000°/s
- 16-bit digital temperature sensor for a -40°C to +105°C operating temperature range
- Compact 2.5mm x 3mm standard size LGA overmold package, 14-pin, 0.83mm height
- Primary digital interface with 10MHz SPI slave (4-wire, 3-wire), 12.5MHz I3C and up to 1MHz I2C (Fm+)
- 0.78125Hz to 6.4kHz nominal sample rate range (ODR)
- Programmable low-pass filtering
- Wide power supply ranges, independent
- 1.71V to 3.63V VDD
- 1.08V to 3.63V VDDIO
- Ultra-low 790µA (typical) current consumption (in full ODR and aliasing-free operation)
- Built-in power management unit (PMU) for advanced power management and low power modes
- Rapid 2.5ms startup time for accelerometer and gyroscope (fast start mode)
- <1ms group delay
- 2KB on-chip FIFO data buffer for accelerometer, gyroscope, temperature, and sensor timestamps
- Fast offset error compensation for accelerometer and gyroscope
- Fast sensitivity error compensation for the gyroscope, <1 maximum sensitivity error
- Hardware synchronization of accelerometer, gyroscope, and temperature (<1µs)
- Sensor time stamps for accurate system (host) and sensor (IMU) time synchronization (<40µs)
- Two independent programmable I/O pins for interrupt and synchronization events
- On-chip interrupt engine and integrated smart features for always-on applications (activity, action, and gesture recognition) using the IMU ultra-low-power domain
- Motion detection
- Step detector
- Plug-and-play step counter
- Orientation and flat detection
- Single tap, double tap, and triple tap detection
- Lead-free, Halogen-free, and RoHS compliant
Applications
- Applications requiring an extended temperature range up to +105°C
- GNSS modules
- Industrial equipment and agriculture
- Robotics
- Smart homes
- Navigation systems
Specifications
- 12.5Hz to 6.4kHz output data rate range, selectable
- Offset soldered, over life
- ±50mg for the accelerometer
- ±1°/s for the gyroscope
- TCO
- ±0.3mg/K for the accelerometer
- Gyroscope
- ±0.01°/s/K from -10°C to +85°C
- ±0.02°/s/K from -40°C to <-10°C and from >+85°C to +105°C
- Sensitivity error
- 0.5% for the accelerometer
- 0.7% for the gyroscope (with CRT)
- Noise density
- 180µg/√Hz for the accelerometer
- 0.007°/s/√Hz for the gyroscope
- Current consumption (accelerometer and gyroscope)
- 790µA in high-performance mode
- 390µA in low-power mode
- 15µA in suspend mode
- I3C, I2C, and SPI interfaces
- 2x interrupt pins for (I2C and I3C)
- 1x interrupt pin (3-wire SPI)
- High performance, normal, low power, and suspend modes
- 2KB on-chip FIFO data buffer
- -40°C to +105°C operating temperature range
- Interrupts
- Motion detection
- Step detector
- Plug-and-play step counter
- Orientation and flat detection
- Single/double/triple tap detection
- Generic interrupts
- 2.5mm x 3.0mm x 0.83mm packge dimensions
Resources
Develoment Tools
Bosch BMI330 Shuttle Board 3.0
Versatile evaluation tool designed to simplify the development and testing of the BMI330 IMU.
Bosch BMI323 Shuttle Board
PCB with a BMI323 6-axis Inertial Measurement Unit.
